CLASSIC LINE CONTRA ANGLES
INTERCHANGEABLE CLASSIC HEADS
Developed for versatility, the interchangeable Classic Heads are time-saving and improve sustainability. Simply turn the tension ring of the contra-angle handpiece and choose between several drill heads for a variety of indications. Made out of stainless steel and coated with chrome for long-term longevity.
| MK-DENT CLASSIC LINE CONTRA ANGLE HEAD | MK-DENT CLASSIC LINE CONTRA ANGLE HEAD | MK-DENT CLASSIC LINE CONTRA ANGLE HEAD | MK-DENT CLASSIC LINE CONTRA ANGLE HEAD | MK-DENT CLASSIC LINE STRAIGHT HANDPIECE | MK-DENT CLASSIC LINE CONTRA ANGLE, LUX | MK-DENT CLASSIC LINE CONTRA ANGLE, LUX | |
|
Reference Number |
LCH11 |
LCH16 |
LCH21 |
LCH21P |
LC01L |
LC11L |
LC27L |
| Light | – | – | – | – | √ | √ | √ |
| Type | Head | Head | Head | Head | Straight Handpiece | Contra Angle | Contra Angle |
| Head Dimensions (mm) | Ø 9.8 x H 14.3 | Ø 9.8 x H 14.8 | Ø 9.8 x H 14.3 | Ø 9.5 x H 16.7 | – | – | – |
| Gear Ratio | 1:1 blue | 1:1 blue | 2:1 green | 2:1 green | 1:1 blue | 1:1 blue | 2,7:1 green |
| Usable Burs | CA-burs (Ø 2.35 mm) | FG-burs (Ø 1.6 mm) | CA-burs (Ø 2.35 mm) | Prophy Cup | HP-burs (Ø 2.35 mm) | – | – |
| Coupling Type | ISO | ISO | ISO | ISO | ISO | ISO | ISO |
|
KEY FEATURES |
|||||||
| Bur Guide | Steel insert | Steel insert | Steel insert | Steel insert | – | – | – |
| Back Cap | Push button | Push button | Push button | – | – | – | – |
| Coating | Chrome | Chrome | Chrome | Chrome | Chrome | Chrome | Chrome |
| Spray Outlet | – | – | – | – | Single | Single | Single |
|
TECH SPECS |
|||||||
| Non-load Speed (rpm) | 40 000 | 40 000 | 20 000 | 20 000 | 40 000 | 40 000 | 14 814 |
| Weight (g) | 12 | 12 | 12 | 12 | 66 | 70 | 66 |
| Warranty (months) | 24 | 24 | 24 | 24 | 30 | 30 | 30 |
HEADS & CONTRA ANGLES CL ASSIC LINE
| MK-DENT CLASSIC LINE CONTRA ANGLE, LUX | MK-DENT CLASSIC LINE STRAIGHT HANDPIECE | MK-DENT CLASSIC LINE CONTRA ANGLE | MK-DENT CLASSIC LINE CONTRA ANGLE | MK-DENT CLASSIC LINE CONTRA ANGLE | |
|
Reference Number |
LC74L |
LC01 |
LC11 |
LC27 |
LC74 |
| Light | √ | – | – | – | – |
| Type | Contra Angle | Straight Handpiece | Contra Angle | Contra Angle | Contra Angle |
| Head Dimensions (mm) | – | – | – | – | – |
| Gear Ratio | 7,4:1 green | 1:1 blue | 1:1 blue | 2,7:1 green | 7,4:1 green |
| Usable Burs | – | HP-burs (Ø 2.35 mm) | – | – | – |
| Coupling Type | ISO | ISO | ISO | ISO | ISO |
|
KEY FEATURES |
|||||
| Bur Guide | – | – | – | – | – |
| Back Cap | – | – | – | – | – |
| Coating | Chrome | Chrome | Chrome | Chrome | Chrome |
| Spray Outlet | Single | Single | Single | Single | Single |
|
TECH SPECS |
|||||
| Non-load Speed (rpm) | 5 406 | 40 000 | 40 000 | 14 814 | 5 406 |
| Weight (g) | 66 | 66 | 70 | 66 | 66 |
| Warranty (months) | 30 | 30 | 30 | 30 | 30 |
LONG-LIFE GEARS
At the heart of every outstanding contra-angle handpiece are exceptional gears. MK-dent Long-Life Gears are engineered to excel at every angle, encouraging complete synthesis between dentist and instrument. Optimized for vibration-free performance thanks to improved torque ratio and class-leading precision.
HEADS & CONTRA ANGLES CL ASSIC LINE
